WATER AND ICE |
|
||||||
|
|
RefriVerde Industrial Air Conditioning and Refrigeration
Engineered Equipment manufactured according to end User requirements by RefriVerde Designs and Specifications
|
RVS Plates Cooler Package
|
|||||
|
|
RefriVerde proposes innovative technologies for the Water Cooling and Ice Production for applications in Air Conditioning and Refrigeration Systems
► Thermal Storage Systems (TES) with Liquid Ice (Fluid) ► Vacuum Water Cooling and Ice Making using Water as Refrigerant with Centrifugal Compressor ► Cooling with the Absorption Cycle using Ammonia as Refrigerant ► Air Cooled Ammonia Water Chillers , low refrigerant charge , suitable to integrate Refrigeration and Air Conditioning Systems in Supermarkets ► Distributed Equipment (Plug-in) connected to a Water Loop where Chilled Water is used in the Condensers of Refrigeration Equipment
|
|
|||||
|
|
Thermal Storage and Engineered Equipment
► Ice banks for thermal accumulation ► Evaporators for Ice Makers ► Crystallizers , Lyophilization Chambers ► Refrigerant Recirculation Systems
|
|
|||||
|
|
Engineered Equipment with Bitzer or J&E Hall . . . according to requirements
RefriVerde manufactures Special industrial-grade Refrigeration Equipment for Water Cooling and Ice Production in Commercial and Industrial Processes
► Seawater chillers on fishing vessels with RSW system , Bitzer ammonia open screw compressor and titanium heat exchangers ► RSW Systems for Fishing Vessels with standard tank from 36 to 500 M3 ► Power consumption for an Ammonia RSW is the lowest of all available refrigerants . Ammonia is the most environment-friendly refrigerant available ► Variable frequency drive for Compressor and Pumps on demand ► Bitzer compressor with Overhaul intervals of 100,000 hours ► Continuously variable capacity control 10-100% on OSKA9500 series ► The Compressor is not contaminated in the event of burning the Motor ► Coupling and Coupling Housing for the aligned of the Motor ► Seawater-cooled Oil Cooler for increased efficiency ► Titanium tubes and tube sheets in all heat exchangers .Tube joints are expanded and welded ► PLC controller offering automatic operation and monitoring of parameters ► See Data with 2-Pole Electric Motor (60 Hz) in the following link NH3 Seawater Chillers , RSW Systems , Bitzer Open Screw Compressor , Rev.250901
► Water Chillers with HFC-134A , 407C and NH3 ► A single Screw Compressor, Variable Speed ► Water Chillers with low Ammonia load , Air Condensation ► Open Compressor for ease of maintenance and greater reliability ► Coupling Housing for the aligned of the Motor ► Electrical Motor IP 55 , FS 1.15 , Premium IE 3 , 3600 RPM (60 Hz) ► See Data with 2-Pole Electric Motor (60 Hz) in the following link Water Chillers , 134A & 407C with Bitzer Compressor
► Water Chillers in Natural Gas Cogeneration Packages ► Natural Gas or Biomethane Engines , a wise choice when electricity is expensive or difficult to access ► Variable Speed Motor according to Water Temperature ► The best option when additional Hot Water or low pressure steam is required , such as in Hospitals and Hotels ► 3-Stage Heat Recovery (Condenser + Engine Cooling + Exhaust Gases) for Hot Water or Steam supply ► See CCHP Cogeneration Package Data in the following link Water Chillers in CCHP Cogeneration Packages with Natural Gas , Bitzer Open Screw Compressor
► An additional system can be considered for heat recovery to produce energy in an Organic Rankine Cycle (ORC) with Bitzer Expander using HFC-245fa or 134a . . .
|
|
|||||
|
|
|
Refrigeracion Verde S.A.S. Barranquilla , Colombia
Issued in 25.09.01
|
|||||
